Cu Xlpe Strip Armoured Manufacturer in India
When setting up industrial power distribution networks, choosing the right electrical cabling is critical for long-term operational efficiency and safety. Ganpati Wires is a leading Cu XLPE strip armoured manufacturer in India, producing heavy-duty low-voltage power cables built for extreme physical and electrical demands. By pairing high-purity electrolytic copper conductors with thermosetting Cross-Linked Polyethylene (XLPE) insulation and galvanized steel strip armouring, these cables provide superior current-carrying capacity, high thermal stability, and robust mechanical protection.
Outer Sheath: Heavy-duty, weather-resistant PVC or Flame Retardant Low Smoke (FRLS) PVC outer jacket shields against moisture, UV rays, and corrosive chemicals.
Strip Armouring (Flat Steel Strips): Flat galvanized steel strips wrapped around the inner sheath offer surface coverage and crushed-load resistance against heavy compression, direct soil loads, and physical abrasion.
Outer Sheath: Heavy-duty, weather-resistant PVC or Flame Retardant Low Smoke (FRLS) PVC outer jacket shields against moisture, UV rays, and corrosive chemicals.
Core Advantages of Cu XLPE Strip Armoured Cables
1. Superior Current-Carrying Capacity
XLPE insulation allows the copper conductor to operate safely at higher continuous temperatures ($90^\circ\text{C}$) compared to PVC-insulated cables ($70^\circ\text{C}$). This higher rating enables a smaller conductor cross-section to handle heavier current loads without overheating.
2. High Resistance to Crush & Compression
Flat steel strip armouring wraps around the inner bed, distributing mechanical pressure evenly across a wider surface area. This prevents internal wire damage under heavy direct-burial loads, trenching, or concrete pour installations.
3. Excellent Short-Circuit Thermal Limits
In short-circuit conditions, XLPE insulation tolerates emergency temperature spikes up to $250^\circ\text{C}$ without melting or deforming, preventing catastrophic breakdown in industrial utility networks.
4. Resistance to Environmental Hazards
With a tight, moisture-proof outer sheath, Ganpati Wires strip armoured cables resist water ingress, soil acids, oil splatters, and atmospheric weathering.
Why Choose Ganpati Wires?
Ganpati Wires brings expertise in non-ferrous conductors and insulated power cable manufacturing.
State-of-the-Art Production: Precision extrusion lines ensure accurate insulation thickness, concentric core cabling, and uniform strip armouring.
Rigorous Testing Standards: Every cable drum undergoes conductor resistance, high-voltage withstand, elongation, and dielectric insulation resistance tests before dispatch.
Custom Engineering Solutions: Multi-core configurations, custom conductor cross-sections, and specialized FRLS or Zero Halogen (ZHLS) outer sheathing available upon request.
Pan-India Logistics: Timely delivery across project sites in India with reliable customer support.
Frequently Asked Questions (FAQs)
Strip armouring uses flat steel strips that offer high surface coverage, ideal for resisting crushed-load pressures in fixed direct underground burial applications. Wire armouring uses round galvanized wires, providing higher tensile strength and flexibility for installations requiring tight bending angles.
XLPE insulation supports higher continuous operating temperatures ($90^\circ\text{C}$ vs. $70^\circ\text{C}$ for PVC) and emergency short-circuit tolerances ($250^\circ\text{C}$). This provides higher current carrying capacity, lower dielectric loss, and longer overall service life.
Yes. The combination of flat steel strip armouring and a durable PVC/FRLS outer sheath allows direct burial in ground trenches without requiring secondary protective conduit piping.
Ganpati Wires manufactures Cu XLPE strip armoured cables in full compliance with IS 7098 (Part 1) specifications, utilizing conductors built to IS 8130 and quality systems certified under ISO 9001:2015.
